FSATECH POE-01102
FSATECH POE-01102

FSATECH POE-01102


PoE Injector, 10/100Mbps, passive POE 48V, 24W


1. Voltage output: DC48V no-load error ± 3%

2.Current output: 500mA

3.AC  input: 170 ~ 230V 50 ~ 60HZ China GB two-plug, line length L = 900mm

4. RJ45 network block: 8P8C network block * 2 a Poe port a LAN port

5. Size: 85 * 45 * 30MM

6. Power Pin: (4/5 +)(7/8 -) power 1/2/3/6 data

7. Speed: 10/100 Megabytes

8. Color: white

9. Operating Temperature: -10 ~ 60 ° C

10. Effective transmission distance: CAT5E/CCA70M/BC110M Cat6/CCA80M/BC120M CAT6e/CCA90M/BC140M (for the stability of data transmission recommendations within 100M use) with LAN connection line!
